Tapping Bands

Tapping Bands

The RMC Tapping Band Range delivers proven performance in a proven design. The range comes in sizes from 40 to 600mm, with take-offs from
20 to 50mm.

  • Quality guaranteed Standards Marked product
  • Standards marked – AS/NZS 4793
  • Lip type seal AS 1646
  • Cast DR Gunmetal body
  • Stainless Steel (316) bolts
  • Maximum operating pressure 1.9 MPa
  • Ease of installation and reduced leakage due to its patented lip seal
  • Long life performance, through its high quality components
  • Light weight construction for ease of handling
  • Type F Series 1
  • Type R
  • Coated
  • Maintenance Types are excluded from the current standard For use on AC or oversized AC pipe
  • Product material configuration may vary over size range
  • Items marked with * indicate reducing bushes are to be used to accommodate smaller off-takes
  • Items marked with ** indicate standard with s/s bolts
  • Items marked with + indicates approved utility use only. No WaterMark
  • Insulation may be required for Bi-Metallic contact
Coated Tapping Saddles for DI and CI Pipe

12501 **

100mm x 20mm

12502 **

100mm x 25mm

12506 **

150mm x 20mm

12507 **

150mm x 25mm

Tapping Saddles – Maintenance Type

12342+

80mm x 25mm

12351+

100mm x 20mm

12352+

100mm x 25mm

12355+

100mm x 50mm

12371+

150mm x 20mm

12372+

150mm x 25mm

12375 *+

150mm x 50mm

12392+

225mm x 25mm

12395 *+

225mm x 50mm

12397+

300mm x 25mm

12400 *+

300mm x 50mm

Tapping Saddles for AC and Compatible Pipe – Series 2

12137 **

58mm x 20mm

12138 **

58mm x 25mm

12141 **

80mm x 20mm

12142 **

80mm x 25mm

12145 **

80mm x 50mm

12151 **

100mm x 20mm

12152 **

100mm x 25mm

12153 **

100mm x 32mm

12154 **

100mm x 40mm

12155 **

100mm x 50mm

12171 **

150mm x 20mm

12172 **

150mm x 25mm

12173 **

150mm x 32mm

12174 **

150mm x 40mm

12175 **

150mm x 50mm

12181 **

200mm x 20mm

12182 **

200mm x 25mm

12185 **

200mm x 50mm

12191

225mm x 20mm

12192

225mm x 25mm

12195

225mm x 50mm

12201

250mm x 20mm

12202

250mm x 25mm

12205

250mm x 50mm

12221

300CD x 20mm

12222

300CD x 25mm

12225

300CD x 50mm

12231+

375mm x 20mm

12232+

375mm x 25mm

12235+

375mm x 50mm

12245+

450mm x 50mm

12255+

500mm x 50mm

12275+

600mm x 50mm

Tapping Saddles – White PVC Series 1

12012 **

50mm x 25mm

12014 **

63mm x 20mm Poly

12015 **

63mm x 25mm Poly

12031 **

80mm x 20mm

12032 **

80mm x 25mm

12034 **

80mm x 40mm

12035 **

80mm x 50mm

12041 **

100mm x 20mm

12042 **

100mm x 25mm

12043 **

100mm x 32mm

12044 **

100mm x 40mm

12045 **

100mm x 50mm

12061 **

150mm x 20mm

12062 **

150mm x 25mm

12063 **

150mm x 32mm

12064 **

150mm x 40mm

12065 **

150mm x 50mm

12086

200mm x 20mm

12087

200mm x 25mm

12089

200mm x 40mm

12090 *

200mm x 50mm

12091

225mm x 20mm

12092

225mm x 25mm

12101

250mm x 20mm

12102

250mm x 25mm

12105 *

250mm x 50mm

12121

300mm x 20mm

12122

300mm x 25mm

12125 *

300mm x 50mm

WMK025661
AS/NZS 4793

12501
