Reduced Pressure Zone Device

Reduced Pressure Zone Device

The RMC/Flomatic Reduced Pressure Zone Device is designed to give maximum protection to the potable water supply from contamination in high hazard applications such as cooling towers, abattoirs and sewage treatment plants.

  • Maximum protection against back siphonage and back pressure
  • Internal by-pass passage (no external plumbing)
  • Designed for easy and quick in-line maintenance and testing
  • Low head loss
  • Corrosion resistant
  • Maximum working pressure of 1200kPa
  • Operating temperature range of 1°C to 82°C up to 50mm BSP Threaded
  • Operating temperature range of 1°C to 60°C from 65mm to 200mm Flanged Table E
  • Approved to AS 2845-1
15mm

SR001

Device Only

SR001C

Complete

SR001C-L

Complete with Lockable Ball Valve

20mm

SR002

Device Only

SR002C

Complete

SR002C-L

Complete with Lockable Ball Valve

25mm

SR003

Device Only

SR003C

Complete

SR003C-L

Complete with Lockable Ball Valve

32mm

SR004

Device Only

SR004C

Complete

SR004C-L

Complete with Lockable Ball Valve

40mm

SR005

Device Only

SR005C

Complete

SR005C-L

Complete with Lockable Ball Valve

50mm

SR006

Device Only

SR006C

Complete

SR006C-L

Complete with Lockable Ball Valve

65mm

SR007

Device Only

SR007C

Complete

80mm

SR008

Device Only

SR008C

Complete

100mm

SR009

Device Only

SR009C

Complete

150mm

SR010

Device Only

SR010C

Complete

200mm

SR011

Device Only

SR011C

Complete

AS/NZS 2845.1
WMKA 25926

SR001
